#14 MQTT and Siemens PLCSim Advanced, another protocol tested and working

Hi everyone,

MQTT is a very important protocol in IoT and IIoT and could be a great thing if we could test our projects using just Siemens PLCSim Advanced and without a real PLC. So I tested if we could do some comunication with a Mosquitto Broker and Node-red with a little Dashboard and it worked quite well

So finally we could publish data from de Simulated PLC and subscribe the PLC to data from Node-red and from Internet. You can see how it works in next video.

Cheers.
